IntelligentTouchPanel is an Americanbase wall switch,integrating Bluetooth5.0 SIG Mesh and DMX signals.It is a simple but elegant design with CNC aviation aluminum frameand 2.5D temperedglass.Thepanelis suitablefor multi-sceneand multi-zone lightingcontrol applications. Working with Bluetooth systems makes it m oreconvenient and intelligent.
| Control Type | DIM |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB1/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | CT |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB2/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | RGB/RGBW/RGBCW |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB5/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | Scene Control |
| Working Voltage | 3Vdc (1xCR2032 button battery) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Compatible Driver | B5-3A |
| Working Temperature | -15°C~50°C |
| Dimensions | 145x40x12mm(LxWxH) |
| Package Size | 148.5x46x19mm(LxWxH) |
| Weight | 50g±10g |
| Input signal | Bluetooth 5.2 SlG Mesh |
| Input voltage | 12-24V |
| Output voltage | 12-24V |
| Load current | 3Ax5CH Max.15A |
| Load power | 180W@12V 360W@24V |
| Protection | Short circuit, over-temperature, over-current protection, anti-reverse connection protection |
| Operating temperature | -25°C ~ 50°C |
| Dimensions | L91xW37xH21(mm) |
| Package Size | L94xW39xH22(mm) |
| Weight (G.W) | 46g |
| Wireless Protocol Type | Bluetooth 5.0 SIG Mesh,DMX/RDM |
| Output Voltage | 5-24Vdc |
| Input Voltage Range | 5-24Vdc |
| Load Current | 4A×5CH / 5A×4CH Max. 20A |
| Load Power | (0~20W...96W)×5CH Max. 480W |
| Protection | Short circuit, overcurrent, overheat, anti-reverse protection |
| Working Temperature | -20°C ~ 55°C |
| Dimensions | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Weight (G.W) | 130g |
| Input Voltage | 12-24VDC, Powered by Class 2 Power Supply |
| Wireless Type | Bluetooth 5.0 SlG Mesh |
| Compatible Devices | B5-3A, Bluetooth Driver, Bluetooth Controller |
| Number of Scene | 8 |
| Working Temperature | -25°C~50°C |
| Dimensions (L×W×H) | L120xW75xH30(mm) |
| Package size (L×W×H) | L158xW113xH62(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBWY |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBW |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | CT |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | DIM |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
