| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Dimensions | L150×W46×H18mm |
| Weight | 80g |
F4-5A Receiving controller |
|
| Working Frequency | 2.4GHz |
| Input voltage | DC5V~DC24V |
| Max current load | 5A x4CH Max 20A |
| Max output power | 100W/240W/480W(5V/12V/24V) |
| Working temperature | -30℃～55℃ |
| Dimensions | L175×W44×H30mm |
| Package size | L178×W48×H33mm |
| Weight (G.W.) | 150g |
F4-3A Receiving controller |
|
| Working Frequency | 2.4GHz |
| Input voltage | DC5V~DC12V |
| Max current load | 3A x4CH Max 12A |
| Max output power | 60W/144W/288W(5V/12V/24V) |
| Working temperature | -30℃～55℃ |
| Dimensions | L125×W33×H20mm |
| Package size | L127×W35×H22mm |
| Weight (G.W.) | 60g |
