| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥84% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 100-450mA |
| Output Power: | 0.9W-15W |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥88% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 300-1050mA |
| Output Power: | 2.7W-45W |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥84% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 150mA |
| Output Power: | 1.35W-6.3W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥85% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 180mA |
| Output Power: | 1.62W-7.56W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥86% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 200mA |
| Output Power: | 1.8W-8.4W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥86% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 220mA |
| Output Power: | 1.98W-9.24W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥86% at full load |
| Power Factor: | PF>0.9 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 250mA |
| Output Power: | 2.25W-10.5W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥87% at full load |
| Power Factor: | PF>0.95 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 300mA |
| Output Power: | 2.7W-12.6W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 220-240Vac |
| PWM Frequency: | Non dimming |
| Output Type: | Constant Current |
| Output Feature: | Isolation |
| Protection Grade: | IP20 |
| Efficiency (Typ.): | ≥87% at full load |
| Power Factor: | PF>0.95 at full load |
| Output Voltage: | 9-42Vdc |
| Output Current: | 350mA |
| Output Power: | 3.15W-14.7W |
| Certification: | CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP |
| Warranty: | 5 years |
| Input Voltage: | 48Vdc±5% (No polarity) |
| Efficiency (Typ): | 94% |
| Output Voltage: | 9~46Vdc |
| Output Current: | 100-800mA |
| Output Power: | 0.9W-33.6W |
| Standby Power: | <0.5W |
| Certification: | CE,ROHS,FCC |
| Warranty: | 5 years |
