中文 | Stock Code:
832110
| Input voltage | 100-240Vac |
| Output signal | RF 2.4GHz, DMX512 |
| Wireless Type | RF 2.4GHz |
| Working Temp. | -20°C~55°C |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Input Voltage: | 5~24Vdc |
| Output Signal: | DMX512 |
| Wireless Signal: | RF 2.4GHz |
| Zones: | 16 |
| DMX Channels: | 1-512 |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
| Control Type | Dim / CT |
| Wireless Signal | RF 2.4GHz |
| Input Voltage | 100-240Vac |
| Output Signal | 0-10V×2 |
| Output Current | 15mA×2 Channel |
| Power Consumption | 1W |
| Dimensions | 86×86×36mm (LxWxH) |
| Package Size | 113×12×50mm (LxWxH) |
| Weight(G.W.) | 225g |
| Remote Type | 4 zones control |
| Working Temp. | -20℃~55℃ |
| Power Supply | 7th battery × 2 |
| Package | L166×W47×H22(mm) |
| Wireless Type | RF 2.4GHz |
| Weight(G.W.) | 85g |
| Input Voltage | 100～240Vac 50-60Hz |
| Output | 0~10V Max. 50mA |
| Switching Power | 90~250Vac, 5A |
| Wireless Signal | RF 2.4GHz |
| Working Temp | -10℃～55℃ |
| Dimensions | L86×W86×H50(mm) |
| Package Size | L106×W106×H60(mm) |
| Weight(G.W) | 220g |
| Dimming interface | DMX/RDM |
| Wireless signal | RF 2.4GHz |
| Input voltage | 5-24Vdc |
| Output voltage | 5-24Vdc |
| Current load | 4A*5CH Max. 20A |
| Output power | (0~20W...96W)*5CH Max. 480W |
| Working temperature | -30℃～55℃ |
| Product size | L175×W44×H30mm |
| Package size | L178×W48×H33mm |
| Weight(G.W.) | 130g |
| Control Mode | RF wireless control and touch panel control |
| Input Voltage | 100-240Vac |
| Load inrush current | Max. 60A |
| Wireless Signal | RF 2.4GHz |
| Working Temp. | -20℃~55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Control Mode | RF wireless control and 0-10V, 10VPWM output control. |
| Input Voltage | 100-240Vac |
| Output Signal | 0-10V |
| Wireless Signal | RF 2.4GHz |
| Working Temp. | -20℃~55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Remote Type | 4 zones control |
| Working Temp. | -20℃~55℃ |
| Power Supply | 7th battery × 2 |
| Package | L166×W47×H22(mm) |
| Wireless Type | RF 2.4GHz |
| Weight(G.W.) | 85g |
| Remote Type | 4 zones control |
| Working Temp. | -20℃~55℃ |
| Power Supply | 7th battery × 2 |
| Package | L166×W47×H22(mm) |
| Wireless Type | RF 2.4GHz |
| Weight(G.W.) | 85g |
| Remote Type | 4 zones control |
| Working Temp. | -20℃~55℃ |
| Power Supply | 7th battery × 2 |
| Package | L166×W47×H22(mm) |
| Wireless Type | RF 2.4GHz |
| Weight(G.W.) | 85g |
| Input voltage | 12-24Vdc |
| Output signal | RF 2.4GHz |
| Working temperature | -10℃~55℃ |
| Output power | 0~72W...144W |
| Output current | 6A×1CH |
| Dimensions | L86×W86×H50(mm) |
| Package Size | L106×W106×H60(mm) |
| Weight(G.W.) | 235g |
| Input Voltage: | 100~240Vac |
| Wireless Signal: | RF 2.4GHz |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
| Working Frequency | 2.4GHz |
| Input voltage | 12~48Vdc |
| Output Voltage | 3~46Vdc |
| Output Current | CC 350/700/1050mA×4CH |
| Output Power | -1.05W~48.3W×4CH Max 193.2W |
| Working Temperature | -30℃~55℃ |
| Package size | L178×W48×H33(mm) |
| Weight (G.W.) | 165g |
| Input voltage | 100~240Vac |
| Output signal | RF 2.4GHz, DMX512 |
| Working temperature | -10℃~55℃ |
| Dimensions | L86×W86×H50(mm) |
| Package Size | L106×W106×H60(mm) |
| Weight(G.W.) | 235g |
| Input Voltage: | 5~24Vdc |
| Output: | 10VPWM |
| Wireless Signal: | RF 2.4GHz |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
| Communication standard: | 2.4GHz WiFi, 802.11b/g/n Protocol |
| Input voltage: | 12~24Vdc |
| Max current load: | 4A x4CH Max 16A |
| Max output power: | (0~48W...96W)×4CH Max. 384W |
| Control distance: | Max. 100m (eye to eye) |
| Working temperature: | -30℃~55℃ |
| Dimensions: | L128×W73×H45(mm) |
| Package size: | L160×W110×H50(mm) |
| Weight (G.W.): | 470g |
| Input Voltage | 12-24Vdc |
| Current Load | 4A×2CH Max 8A |
| Output Power | (0~48W...96W)×2CH Max. 192W |
| Working Temp. | -30℃～55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Input Voltage | 12-24Vdc |
| Current Load | 4A×2CH Max 8A |
| Output Power | (0~48W...96W)×2CH Max. 192W |
| Working Temp. | -30℃～55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Input voltage | 100-240Vac |
| Output signal | RF 2.4GHz, DMX512 |
| Control mode | Synchronous control |
| Working temperature | -30℃~55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Input voltage | 100-240Vac |
| Output signal | RF 2.4GHz, DMX512 |
| Control mode | Synchronous control |
| Working temperature | -30℃~55℃ |
| Dimensions | L86×W86×H36(mm) |
| Package Size | L113×W112×H50(mm) |
| Weight(G.W.) | 225g |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working voltage | DC3V(Battery CR2032 ) |
| Working Frequency | RF 2.4G |
| Remote Distance | 20m(line of sight) |
| Working Temp. | -30℃～55℃ |
| Working Frequency | 2.4GHz |
| Input voltage | DC5V~DC24V |
| Max current load | 3A x4CH Max 12A |
| Max output power | 60W/144W/288W(5V/12V/24V) |
| Remote Distance | 50m (line of sight) |
| Working temperature | -30℃～55℃ |
| Dimensions | L125×W33×H20mm |
| Package size | L127×W35×H24mm |
| Weight (G.W.) | 60g |
| Working Frequency | 2.4GHz |
| Input voltage | DC5V~DC24V |
| Max current load | 5A x4CH Max 20A |
| Max output power | 100W/240W/480W(5V/12V/24V) |
| Remote Distance | 50m (line of sight) |
| Working temperature | -30℃～55℃ |
| Dimensions | L175×W44×H30mm |
| Package size | L178×W48×H33mm |
| Weight (G.W.) | 150g |
| Input voltage | 100~240V AC |
| Output signal | RF 2.4G+DMX512 |
| Control mode | 4 zones control |
| Wireless distance | 30m |
| Working temperature | -30℃～55℃ |
| Dimension | L86×W86×H36mm |
| Package Size | L113×W112×H50mm |
| Weight (G.W) | 225g |
| Input voltage | 100~240V AC |
| Output signal | RF 2.4G+DMX512 |
| Control mode | 4 zones control |
| Wireless distance | 30m |
| Working temperature | -30℃～55℃ |
| Dimension | L86×W86×H36mm |
| Package Size | L113×W112×H50mm |
| Weight (G.W) | 225g |
| Input voltage | 100~240V AC |
| Output signal | RF 2.4G+DMX512 |
| Control mode | 4 zones control |
| Wireless distance | 30m |
| Working temperature | -30℃～55℃ |
| Dimension | L86×W86×H36mm |
| Package Size | L113×W112×H50mm |
| Weight (G.W) | 225g |
| Input voltage | 100~240V AC |
| Output signal | RF 2.4G+DMX512 |
| Control mode | sync control |
| Wireless distance | 30m |
| Working temperature | -30℃～55℃ |
| Dimension | L86×W86×H37mm |
| Package Size | L113×W112×H50mm |
| Weight (G.W) | 225g |
| Input voltage | 100~240V AC |
| Output signal | RF 2.4G+DMX512 |
| Control mode | sync control |
| Wireless distance | 30m |
| Working temperature | -30℃～55℃ |
| Dimension | L86×W86×H36mm |
| Package Size | L113×W112×H50mm |
| Weight (G.W) | 225g |
